Field replaceable units:
Replace main unit parts
2000966
-542D
Dash 30
00/4000/5
000
7-35
flat end of a pen a
pproximately 1- i
nch deep and push
the CF flash
card eject button as shown.
5.
Carefully disconnect the antennas
using a pen tip,
small screwdriver,
or needl
e nose
plie
rs.
973A
974A
CF card ej
ect button
942A
180
182
