Chapter 2. Initial Setup
18 DigitalFlow™ Multipurpose Ultrasonic Liquid Flowmeter Startup Guide (1- and 2-Channel)
2.3 Accessing the User Program
To access the User Program, press the [PROG] key on the keypad.
Note: If the security feature is active, enter the password and press [ENT] to enter the User Program. See the SECUR
submenu section in Chapter 1 of the Programming Manual for more information on the security feature.
2.3.1 1-Channel Meter
For a 1-Channel Model DF868, the measurement mode screen is replaced by the following initial programming mode
screen:
2.3.2 2-Channel Meter
For a 2-Channel Model DF868, the following two-step sequence is required to reach the initial programming screen:
Only the submenus
ACTIV, SYSTM and PIPE are discussed in this manual. Refer to the Programming Manual for
information on the other submenus.
Note: In this manual, only the programming of Channel 1 will be described. To program Channel 2, simply repeat the
same procedures presented for Channel 1.
PROGRAM Start ‰
At the User Program screen
shown, press [F1] and proceed to
the next page for instructions.
PROGRAM
status
ACTIV SYSTM PIPE I/O
PROGRAM Start ‰
Press [F1] or [F2] to select the
submenu for Channel 1 or
Channel 2, respectively, from the
option bar.
PROGRAM
Channel 1
CH1 CH2 GLOBL SAVE
Chan 1 PROGR Start ‰
At the User Program screen
shown, press [F1] and proceed to
the next page for instructions.
Channel PROGRAM
status
ACTIV SYSTM PIPE I/O
To Next Page
