DigitalFlow™ Multipurpose Ultrasonic Liquid Flowmeter Startup Guide (1- and 2-Channel) 29
Chapter 2. Initial Setup
2.7 Exiting the User Program
After the calibration factor entry has been made, the meter will exit the PIPE submenu and return to the initial User
Program screen.
At the conclusion of the initial setup programming sequence, the following screen appears:
Note: If you press
[NO], the DF868 still retains the newly programmed information. See the Programming Manual for
instructions on using the SAVE submenu.
Proceed to Chapter 3, Operation, for instructions on taking measurements or refer to the Programming Manual for
instructions on programming the Model DF868’s advanced features.
PROGRAM Start ‰
To leave the User Program and
begin taking measurements,
press [EXIT].
PROGRAM
status
ACTIV SYSTM PIPE I/O
PROGRAM Start
At the User Program screen
shown, press [F1] to return to
measurement mode without
saving the file or press [F2] to
enter the SAVE submenu.
Do you want to SAVE
current selection appears here
No Yes
