GE DigitalFlow DF868 Startup Guide

DigitalFlow™ Multipurpose Ultrasonic Liquid Flowmeter Startup Guide (1- and 2-Channel) 27
Chapter 2. Initial Setup
2.6.8 Fluid Type
10. Use the [F1]-[F4] and [ keys to select the Fluid Type. The selections for fluid type vary, depending on whether:
• the ENERGY OPTION is ON or OFF; and
• the TRACKING WINDOW is enabled or disabled.
Refer to Table 10 if
ENERGY OPTION is OFF, or to Table 11 on page 27 if ENERGY OPTION is ON.
Note: Some of the fluid types may require additional selections as shown in the following tables.
Table 10: Fluid Types for ENERGY OFF
Tracking Windows =
NO Additional Selections YES Additional Selections
WATER Select
NORML or SEA and press [ENT].
If
NORML is selected, enter the Water
Temperature and press
[ENT].
W100 No additional selections required.
OIL Select
LUBE or CRUDE and press [ENT]. W260 No additional selections required.
METH No additional selections required. OIL No additional selections required.
ETH Enter the Fluid Soundspeed and press
[ENT].
OTHER Enter the Minimum Soundspeed and press
[ENT]. Then enter the Maximum Soundspeed
and press
[ENT]
LN2 No additional selections required.
FREON No additional selections required.
OTHER Enter the Fluid Soundspeed and press
[ENT].
Table 11: Fluid Types for ENERGY ON
Tracking Windows =
NO Additional Selections YES Additional Selections
WATER Enter the Water Temperature and press
[ENT].
W260 No additional selections required.
MIXED Enter the Fluid Soundspeed and press
[ENT]. Then enter the Percentage of
Water and press
[ENT].
MIXED Enter the Percentage of Water and press [ENT].
OTHER Enter the Fluid Soundspeed and press
[ENT].
OTHER Enter the Minimum Soundspeed and press
[ENT]. Then enter the Maximum Soundspeed
and press
[ENT].
