Chapter 3: Programming
164 EST iO64 and iO500 Technical Reference Manual
2 wire Class B: Allows for the monitoring of two-wire conventional smoke detectors in a Class B
circuit (that do not require alarm verification) and normally open contact initiating devices on
the same circuit
2 wire verify Class B: Allows for the monitoring of two-wire conventional smoke detectors in a
Class B circuit (that require alarm verification)
2 wire Class A: Allows for the monitoring of two-wire conventional smoke detectors in a Class A
circuit (that do not require alarm verification) and normally open contact initiating devices on
the same circuit.
2 wire verify Class A: Allows for the monitoring of two-wire conventional smoke detectors in a
Class A circuit (that require alarm verification)
Audible: Assigned to NACs connected to audible notification appliances that turn off when
Signal Silence is pressed
Visible: Assigned to NACs connected to visible notification appliance that do not turn off when
Signal Silence is pressed
Relay module
Relay nonsilence: For the connection of relay devices that do not follow signal silence.
Relay with silence: For the connection of relay devices that follow signal silence.
00:00:00 A001 D001
001 Trouble
Unconfigured Trouble
Ser# xxxxxxxxxx
⇩
Loop x Device xxx
Device type
⇩
Enter Password
0000
⇩
Add Loop x
Device 001
Device label
<-Continue <Back
⇩
Device 001
Zone 01<>
Label >
Correlation Groups
To add a device:
1. Install the device on your system.
The system recognizes the new device and displays a trouble
event, which indicates that there is an unprogrammed device.
2. Press Enter.
The device details screen is displayed.
3. Press Enter.
The Enter Password screen is displayed if you are not logged on.
If you are already logged on, the Add Device screen is displayed;
go to step 5.
4. Enter a level two password.
The Add Device screen is displayed.
5. Verify the device you are about to add, and then press Enter.
The Device programming menu is displayed. If the device is not
a valid device, "invalid device" is displayed and you won't be
able to program the device.
6. Program the device options using the "Device programming
options" table above.
⇩
