Chapter 3: Programming
EST iO64 and iO500 Technical Reference Manual 165
Some of the device options have a factory default setting that
can be used requiring no additional programming. Refer to
"Factory default settings" for a list of the default settings for a
device.
Note: If you added a dual address device, both addresses for
the device are displayed on the screen (e.g. 001/002). The first
address listed is the device address you are programming.
When you pick the second address to program, both addresses
are still displayed but in reverse order (e.g. 002/001).
Note: Depending on the type of device you are programming,
some of the options in the table below may not be available.
7. When you're finished programming each option, choose Save.
The device is added to the database and the unprogrammed
device event is cleared for that device.
8. Press Menu to exit menu mode.
Device 001
Base Follow Device<>
Type Smoke<>
Save
To Next Page
