GE Evolution Series E9000 User Manual

Evolution Series E9000 User Manual
33
Size 0 and 1 (Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
.66-.76 C087A 3 LO LO
.77-.84 C097A 3 LO LO
.85-.93 C109A 3 LO LO
.94-1.04 C118A 3 LO 2
1.05-1.15 C131A 3 LO 2
1.16-1.27 C148A 3 LO 3
1.28-1.39 C163A 3 LO 3
1.40-1.55 C184A 3 LO 4
1.56-1.73 C196A 3 2 4
1.74-1.89 C220A 3 2 5
1.90-2.05 C239A 3 2 5
2.06-2.28 C268A 3 3 5
2.29-2.47 C301A 3 3 6
2.48-2.79 C326A 7 LO 3
2.80-3.31 C356A 7 LO 4
3.32-3.70 C379A 7 2 4
3.71-4.06 C419A 7 2 4
4.07-4.47 C466A 7 2 5
4.48-4.95 C526A 7 3 5
4.96-5.49 C592A 7 3 6
5.50-5.91 C630A 7 4 6
5.50-5.91 C630A 15 LO 3
5.92-6.47 C695A 15 LO 3
6.48-7.20 C778A 15 2 4
7.21-8.22 C867A 15 2 4
8.23-8.72 C955A 15 2 5
8.73-9.67 C104B 15 3 5
9.68-10.4 C113B 20 2 4
10.5-11.0 C125B 20 2 4
11.1-12.4 C137B 20 2 5
12.5-13.2 C151B 20 3 5
13.3-15.4 C163B 20 4 6
15.5-17.1 C180B 25 3 5
Size 1 (Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
17.2-18.1 C198B 25 3 6
18.2-20.0 C214B 30 3 5
20.1-21.5 C228B 30 3 5
21.6-22.5 C250B 30 3 6
22.6-23.9 C273B 40 2 5
24.0-26.0 C303B 40 3 5
26.1-27.0 C330B 40 3 5
Size 2 (Standard)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
8.81-9.27 C104B 15 3 5
9.28-9.99 C113B 20 2 4
10.0-11.1 C125B 20 2 5
11.2-12.1 C137B 20 3 5
12.2-13.0 C151B 20 3 5
13.1-15.5 C163B 20 4 6
15.6-16.8 C180B 25 3 5
16.9-18.0 C198B 25 3 6
18.1-19.7 C214B 30 3 5
19.8-21.6 C228B 30 3 5
21.7-23.9 C250B 40 2 5
24.0-25.5 C273B 40 2 5
25.6-28.2 C303B 50 2 5
28.3-31.6 C330B 50 3 5
31.7-34.7 C366B 50 3 6
34.8-37.8 C400B 50 3 6
37.9-40.6 C440B 60 3 5
40.7-43.4 C460B 60 3 6
Size 2 (Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
28.8-32.0 F357B 50 3 5
32.1-34.2 F395B 50 3 5
34.3-36.7 F430B 70 2 5
36.8-43.8 F487B 70 3 5
43.9-46.6 F567B 70 3 5
46.7-52.6 F614B 100 2 4
52.7-55.6 F658B 100 2 5
55.7-58.7 F719B 100 2 5
58.8-67.1 F772B 100 3 5
67.2-70.6 F848B 100 3 6
70.7-76.3 F914B 150 2 4
76.4-88.7 F104C 150 2 5
88.8-93.4 F114C 150 3 5
93.5-105.0 F118C 150 3 5
106.0-114.0 F133C 150 3 5
115.0-128.0 F149C 150 4 6
129.0-130.0 F161C 150 4 6
Size 3 (Standard and Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
17.8-18.4 F233B 30 2 5
18.5-21.1 F243B 30 3 5
21.2-22.1 F207B 30 3 5
22.2-26.0 F300B 40 3 5
26.1-28.0 F327B 40 3 5
28.1-31.3 F357B 50 3 5
31.4-33.3 F395B 50 3 5
33.4-34.3 F430B 50 3 5
34.4-40.9 F487B 70 2 5
41.0-44.7 F567B 70 3 5
44.8-51.0 F614B 100 LO 4
51.1-52.0 F658B 100 LO 4
52.1-55.4 F719B 100 2 5
55.5-63.3 F772B 100 3 5
63.4-66.1 F848B 100 3 5
66.2-73.5 F914B 100 3 6
73.6-82.2 F104C 150 2 4
82.3-86.9 F114C 150 2 5
