Evolution Series E9000 User Manual
32
Size 3 (Standard and Ambient Comp.) cont.
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
TEC &
TECL
Rating
Mag-Break
Trip Setting
Rec. Max.
55.5-63.3 F772B 100 1 5
63.4-66.1 F848B 100 2 6
66.2-73.5 F914B 100 2 6
73.6-82.2 F104C 100 2 7
82.3-86.9 F114C 100 3 9
Size 4 (Standard)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
TEC &
TECL
Rating
Mag-Break
Trip Setting
Rec. Max.
28.8-32.0 F357B 50 1 4
32.1-34.2 F395B 50 2 5
34.3-36.7 F430B 50 2 6
36.8-43.4 F487B 50 3 7
43.5-43.9 F487B 100 1 3
44.0-46.6 F567B 100 1 3
46.7-52.6 F614B 100 1 3
52.7-55.6 F658B 100 1 4
55.7-58.7 F719B 100 2 5
58.8-67.1 F772B 100 2 5
67.2-70.6 F848B 100 3 6
70.7-76.3 F914B 100 3 7
70.7-76.3 F914B 150 LO 1
76.4-86.9 F104C 100 4 8
76.4-88.7 F104C 150 LO 2
88.8-93.4 F114C 150 1 3
93.5-102 F118C 150 1 3
103-110 F133C 150 1 4
111-122 F149C 150 1 4
123-131 F161C 150 2 5
Size 4 (Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
TEC &
TECL
Rating
Mag-Break
Trip Setting
Rec. Max.
28.8-32.0 F357B 50 2 4
32.1-34.2 F395B 50 2 5
34.3-36.7 F430B 50 2 6
36.8-43.4 F487B 50 3 7
36.8-43.8 F487B 100 LO 2
43.9-46.6 F567B 100 2 3
46.7-52.6 F614B 100 1 3
52.7-55.6 F658B 100 1 4
55.7-58.7 F719B 100 2 5
58.8-67.1 F772B 100 2 5
67.2-70.6 F848B 100 3 6
70.7-76.3 F914B 100 3 7
76.4-86.9 F104C 100 4 8
76.4-88.7 F104C 150 LO 2
88.8-93.4 F114C 150 1 3
93.5-105 F118C 150 1 3
106-114 F133C 150 1 4
115-128 F149C 150 2 5
129-130 F161C 150 2 6
Size 5 (Standard and Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
TEC &
TECL
Rating
Mag-Break
Trip Setting
Rec. Max.
106-115 C592A 550-1670 2 6
116-125 C630A 550-1670 3 7
126-135 C695A 550-1670 3 7
126-135 C695A 1000-3300 LO 3
136-151 C778A 1000-3300 LO 3
152-164 C867A 1000-3300 LO 4
165-179 C955A 1000-3300 1 5
180-195 C104B 1000-3300 2 5
196-215 C113B 1000-3300 2 6
216-231 C125B 1000-3300 3 6
232-255 C137B 1000-3300 4 7
256-270 C151B 1000-3300 4 HI
Size 0 and 1 (Standard)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
65-.74 C087A 3 LO LO
.75-.84 C097A 3 LO LO
.85-.92 C109A 3 LO LO
.93-1.02 C118A 3 LO 2
1.03-1.10 C131A 3 LO 2
1.11-1.23 C148A 3 LO 2
1.24-1.38 C163A 3 LO 3
1.39-1.49 C184A 3 LO 4
1.50-1.67 C196A 3 LO 4
1.68-1.79 C220A 3 LO 5
1.80-1.98 C239A 3 2 5
1.99-2.24 C268A 3 3 5
2.25-2.43 C301A 3 3 6
2.44-2.75 C326A 7 LO 3
2.76-3.25 C356A 7 LO 4
3.26-3.43 C379A 7 LO 4
3.44-4.03 C419A 7 2 4
4.04-4.43 C466A 7 2 5
4.44-4.94 C526A 7 3 5
4.95-5.36 C592A 7 3 6
5.37-5.77 C630A 7 4 6
5.37-5.77 C630A 15 LO 3
5.78-6.35 C695A 15 LO 3
6.36-6.92 C778A 15 LO 4
6.93-7.99 C867A 15 2 4
8.00-8.47 C955A 15 2 5
8.48-9.19 C104B 15 3 5
9.20-10.0 C113B 20 2 4
10.1-10.7 C125B 20 2 5
10.8-12.0 C137B 20 2 5
12.1-12.9 C151B 20 3 5
13.0-15.1 C163B 20 4 6
15.2-16.3 C180B 25 3 5
16.4-17.9 C198B 25 3 6
Size 1 (Standard)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
SE
Rating
Plug
Mag-Break
Trip Setting
Rec. Max.
18.0-19.7 C214B 30 3 5
19.8-21.2 C228B 30 3 5
21.3-22.3 C250B 30 3 6
22.4-23.5 C273B 40 2 5
23.6-25.5 C303B 40 3 5
25.6-27.0 C330B 40 3 5
