GE Evolution Series E9000 User Manual

Evolution Series E9000 User Manual
36
Size 5 – 300:15 CT (Standard and Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
Maximum
Fuse
Rating
.41-.45 C054A 3
.46-.49 C060A 3
.50-.53 C066A 3
.54-.59 C071A 3
.60-.65 C078A 3
.66-.76 C087A 3
.77-.84 C097A 3
.85-.93 C109A 3
.94-1.04 C118A 3
1.05-1.15 C131A 3
1.16-1.27 C148A 3
1.28-1.39 C163A 3
1.40-1.55 C184A 6
1.56-1.73 C196A 6
1.74-1.89 C220A 6
1.90-2.05 C239A 6
2.06-2.28 C268A 6
2.29-2.47 C301A 6
2.48-2.79 C326A 10
2.80-3.31 C356A 10
3.32-3.70 C379A 12
3.71-4.06 C419A 15
4.07-4.47 C466A 15
4.48-4.95 C526A 15
4.96-5.49 C592A 20
5.50-5.91 C630A 20
5.92-6.47 C695A 25
6.48-7.20 C778A 25
7.21-8.22 C867A 30
8.23-8.72 C955A 30
8.73-9.67 C104B 35
1
9.68-10.4 C113B 35
1
10.5-11.0 C125B 40
1
11.1-12.4 C137B 45
1
12.5-13.2 C151B 50
1
13.3-15.4 C163B 60
1
15.5-17.1 C180B 60
1
17.2-18.0 C198B 60
1
Size 1 (Standard and Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
Maximum
Fuse
Rating
17.2-18.1 C198B 60
1
18.2-20.0 C214B 60
1
20.1-21.5 C228B 60
1
21.6-22.5 C250B 60
1
22.6-23.9 C273B 60
1
24.0-26.3 C303B 60
1
26.4-27.0 C330B 60
1
Size 2 (Standard and Ambient Comp.)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
Maximum
Fuse
Rating
5.48-5.85 C630A 20
5.86-6.47 C695A 20
6.48-7.35 C778A 25
7.36-8.06 C867A 30
8.07-9.03 C955A 30
9.04-9.61 C104B 35
9.62-10.5 C113B 35
10.6-11.6 C125B 40
11.7-12.5 C137B 45
12.6-13.6 C151B 50
13.7-16.7 C163B 60
16.8-17.9 C180B 60
18.0-18.7 C198B 70
1
18.8-20.4 C214B 80
1
20.5-22.7 C228B 80
1
22.8-24.7 C250B 90
1
24.8-26.3 C273B 90
1
26.4-29.5 C303B 100
1
29.6-32.5 C330B 100
1
32.6-36.7 C366B 100
1
36.8-41.9 C400B 100
1
42.0-43.2 C440B 100
1
43.3-45.0 C460B 100
1
Size 3 (Standard)
Motor Full-
Load Amps
3-Ph, 3 Heater
Heater
Number
CR123
Maximum
Fuse
Rating
19.0-19.3 F233B 70
19.4-22.1 F243B 80
22.2-23.4 F270B 80
23.5-27.0 F300B 90
27.1-29.1 F327B 100
29.2-31.8 F357B 110
1
31.9-33.9 F395B 125
1
34.0-37.6 F430B 125
1
37.7-41.9 F487B 150
1
42.0-47.7 F567B 175
1
47.8-52.1 F614B 175
1
52.2-55.8 F658B 200
1
55.9-59.7 F719B 200
1
59.8-68.1 F772B 200
1
68.2-71.5 F848B 200
1
71.6-78.2 F914B 200
1
78.3-87.5 F104C 200
1
87.6-90.0 F114C 200
1
1
See maximum fuse and short-circuit rating table on page 29
