Evolution Series E9000 User Manual
39
Catalog numbers of electronic overloads for various sizes of NEMA
starters and current ranges
NEMA
Size
FLA Range
in Amps
Catalog
Number
Max. Fuse
in Amps
1 0.8 to 1.59 CR324CXD
Time-Delay
Class R&J 30
Time-Delay
Class J 60
1 1.6 to 3.19 CR324CXE
1 3.2 to 6.49 CR324CXF
1 6.5 to 12.8 CR324CXG
1 13 to 27 CR324CXH
2 13 to 25.6 CR324DXG
60 1002 26 to 49.9 CR324DXH
2 50 to 100 CR324DXJ
3 17 to 34.9 CR324FXK
100 2003 35 to 64.9 CR324FXL
3 65 to 90 CR324FXM
4 17 to 34.9 CR324FXK
200 4004 35 to 64.9 CR324FXL
4 65 to 135 CR324FXM
5
1
32 to 64.0 CR324GXN
400 6005
1
65 to 129.9 CR324GXP
5
1
130 to 270 CR324GXQ
6
2
130 to 259.9 CR324HXS 600 Class L 1200
1
300:15 CT’s
2
800:5 CT’s
IEC Style Overload Relays
C2000 Contactor CLNCJ Type RT Overload Relay for 1/2X Starter
Current
Range
Max
CB
Cat. No. Class Cat. No. Class
Lug/
Wire Size
Torque
(in-lbs)
0.4-.65 15 RTN1D 10 RT12D 20 #14-8 14-20
0.65-1.1 15 RTN1F 10 RT12F 20 #14-8 14-20
1-1.5 15 RTN1G 10 RT12G 20 #14-8 14-20
1.3-1.9 15 RTN1H 10 RT12H 20 #14-8 14-20
1.8-2.7 15 RTN1J 10 RT12J 20 #14-8 14-20
2.5-4.1 15 RTNIK 10 RT12K 20 #14-8 14-20
4.0-6.3 15 RTNIL 10 RT12L 20 #14-8 14-20
5.5-8.5 15 RTNIM 10 RT12M 20 #14-8 14-20
8.0-12 30 RTNIN 10 RT12N 20 #14-8 14-20
10.0-16 35 RTNIP 10 RT12P 20 #14-8 14-20
14.5-18 40 RTNIS 10 RT12S 20 #14-8 14-20
17.5-22 50 RTNIT 10 RT12T 20 #14-8 14-20
