GE Evolution Series E9000 User Manual

Evolution Series E9000 User Manual
40
AF-600 FP / AF-650 GP Drives E9000
Panel mount use with RTXP base adapter
Contactor
Cat. No.
FLA Range
Lug/ Wire
Size
Torque
(in-lbs)
Class 10 Class 20
LAR02AJ RTN1B NA 0.16-0.26 #14-8 AWG 14-20
LAR25AJ RTN1C NA 0.27-0.41 #14-8 AWG 14-20
LAR45AJ
RTN1D RT12D 0.42-0.65 #14-8 AWG 14-20
RTN1F RT12F 0.66-1.10 #14-8 AWG 14-20
RTN1G RT12G 1.11-1.50 #14-8 AWG 14-20
RTN1H RT12H 1.51-1.90 #14-8 AWG 14-20
RTN1J RT12J 1.91-2.5 #14-8 AWG 14-20
RTN1K RT12K 2.51-4.10 #14-8 AWG 14-20
RTN1L RT12L 4.11-6.3 #14-8 AWG 14-20
RTN1M RT12M 6.31-8.5 #14-8 AWG 14-20
RTN1N RT12N 8.51-12.0 #14-8 AWG 14-20
RTN1P RT12P 12.1-16 #14-8 AWG 14-20
RTN1S RT12S 16.1-18 #14-8 AWG 14-20
RTN1T RT12T 18.1-22 #14-8 AWG 14-20
RTN1U RT12U 22.1-26 #14-8 AWG 14-20
RTN1V RT12V 26.1-32 #14-8 AWG 14-20
RTN1W RT12W 32.1-40 #14-8 AWG 14-20
LAR08AJ RTN2A NA 11.5-15 #10-3 AWG 50
Mount direct to contactor
Contactor
Cat. No.
FLA Range
Lug/ Wire
Size
Torque
(in-lbs)
Class 10 Class 20
LAR08AJ RTN2B NA 15.1-19 #10-3 AWG 50
LAR10AJ
RTN2C NA 19.1-25 #10-3 AWG 50
RTN2D RT22D 25.1-32 #10-3 AWG 50
RTN2E RT22E 32.1-43 #10-3 AWG 50
RTN2G RT22G 43.1-55 #10-3 AWG 50
RTN2H RT22H 55.1-65 #10-3 AWG 50
RTN2J RT22H 65.1-82 #10-3 AWG 50
RTN2L RT22L 82.1-97 #10-1 AWG 50
RTN2M RT22M 97.1-110 #10-1 AWG 50
KAR08CJ
RTN3B NA 55-80 #6-250 MCM 275
RTN3C RT32C 80.1-90 #6-250 MCM 275
RTN3D RT32D 90.1-120 #6-250 MCM 275
RTN3E RT32E 120.1-140 #6-250 MCM 275
RTN3F RT32F 140.1-190 #6-250 MCM 275
KAR95BYWZ
RTN4N NA* 120-190 #6-350MCM 200
RTN4P NA* 190.1-280 #6-350MCM 200
RTN4R NA* 280.1-310 #6-350MCM 200
KAR95BJWZ
RTN4N NA* 120-190 #6-350 MCM 200
RTN4P NA* 190.1-280 #6-350 MCM 200
RTN4R NA* 280.1-310 #6-350 MCM 200
KAR10BYWZ RTN5A NA* 120-190 #6-350MCM 375
KAR11BYWZ RTN5B NA* 190.1-280 #6-350MCM 375
KAR11BJWZ RTN5B NA* 190.1-280 #6-350 MCM 375
KAR12BJWZ RTN5C NA* 280.1-400 #6-350 MCM 375
KAR12BYWZ
RTN5C NA* 280.1-400 #8-500 MCM 375
RTN5D NA* 400.1-500 #8-500 MCM 375
RTN5E NA* 500.1-650 #8-500 MCM 375
*
Class 30 is available
WZ – Special for Mebane
