– 12 –
4 Pass Heater Algorithm, Dry Cycle
Normal with Heated Dry
Time (minutes)
Calr
od Description
6
Calrod on
28
&DOURG3XOVHPLQXWHRQPLQXWHRȺ
14
&DOURGRȺ&RRO'RZQ
Normal with T
emp Boost or Sani Selected
6
Calrod on
58
&DOURG3XOVHPLQXWHRQPLQXWHRȺ
Tar
get / Max T
emperature Limits
Cycle
P
W4
MW
PR1
FR
Rinse
Light
125
135
Normal
125
140
Auto
130
140
Heavy
130
130
130
145
Heavy +AH
135
135
130
145
CU
NA
130
NA
135
Heated Dry Element Algorithm
11
13
Table of Contents
Safety Information
2
Table of Contents
3
Safety Requirements
6
Nomenclature
7
Introduction
8
Tools Needed
9
Operation and Cycle Information
10
Troubleshooting
13
Flashing Lights
13
Will Not Start
13
Component Locator Views
14
Tub and Structure
20
Tub Trim (some Models)
20
Toe Kick
20
Junction Box and House Wiring Connection
20
Level Legs
21
Door Balance System
21
Hinges
21
Tub Gasket
22
Latch System
23
Latch Switch Diagnosis
23
Racks
24
Lower Rack
25
Silverware Baskets
26
Door
26
Inner Door Vent Cover
28
Front Control Console
29
Front Control UI, Light Pipe and Buttons
30
Pocket Handle (Front Control Only)
30
Top Control Panel, UI, Light Pipe and Buttons
31
Top Control Console Cover
32
Outer Door Panel
32
Inner Door Panel
33
Door Gasket
33
Vent Parts
33
Detergent Dispenser
34
Door Strike
35
Sump Module
36
Sump Gasket
38
Installing Sump Module
38
Consumer Error Mode
39
Electronic Controls
39
Service Mode
40
Diagnosing Electronic Control Boards
40
Main Control Diagnostics
41
On the Main Control Board CSM
42
UI Diagnostics
44
Water Level
45
Fill System
45
Diagnostics
46
Flood Switch and Thermistor
47
Thermistor
48
Fill Funnel and Hose
48
Fill Valve
49
Circulation System
50
Diagnostics
51
No Circulation
52
Filtration
53
Circulation Motor and Pump Assembly
54
Diverter
54
Turbidity Sensor
57
Conduits and Spray Arms
58
Main Conduit
59
Spray Arms
59
Middle Conduit
60
Bottle Wash System (some Models)
61
Upper Spray System
61
Drain System
62
Diagnostics
63
Dry System
65
Heat Element Removal
67
Tub TCO
67
Schematics
68
Gdf520J
68
Gdf610J
68
Gdt535J
69
Adt521J, Gdf610J, Gdf620J, Gdt545J, Gdt625J, Gdt635J
70
Index
71
Dishwasher Warranty
73
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the GE GDT625PxJ Series and is the answer not in the manual?
Ask a question
GE GDT625PxJ Series Specifications
General
Brand
GE
Model
GDT625PxJ Series
Category
Dishwasher
Language
English
