GE iBox User Manual

GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
161
DCA DPA
Source
Data
Type
MODBUS DCA
Register
Address
Point Description
COM1 COM2
DNP DPA
Point
MODBUS DPA
Point Address
DNP TCP/IP
DPA Point
MODBUS DCA
(IBOX-ACA and IBOX-ACL) continued
AI
406 VAR MIN 80 81 80
407 VA MIN 81 82 81
408 PF MIN 82 83 82
409 FREQ MIN 83 84 83
1282 RESET VOLT/AMP/POWER 84 85 84
1284 RESET MAX/MIN/WH 85 86 85
AO
1282 RESET VOLT/AMP/POWER 0 89 0
1284 RESET MAX/MIN/WH 1 90 1
CT
434 WATT HOUR BCD COUNTER 8 N/A N/A N/A
435 WATT HOUR BCD COUNTER 7 N/A N/A N/A
436 WATT HOUR BCD COUNTER 6 N/A N/A N/A
437 WATT HOUR BCD COUNTER 5 N/A N/A N/A
438 WATT HOUR BCD COUNTER 4 N/A N/A N/A
439 WATT HOUR BCD COUNTER 3 N/A N/A N/A
440 WATT HOUR BCD COUNTER 2 N/A N/A N/A
441 WATT HOUR BCD COUNTER 1 N/A N/A N/A
LogicLinx
CT
N/A KWH counter 32bit 0 N/A 0
N/A KWH counter 16bit MSB N/A 87 N/A
N/A KWH counter 16bit LSB N/A 88 N/A
Notes:
• ADAM-4017 AI CH: 00 to 07 are converted by the Calculator DTA into two's compliment numbers
which are stored in the system point database (Scaled Analog Input #1 to 8).
• WATT HOUR BCD COUNTER 1 to 8 of the AC meter are ASCII BCD numbers. These numbers are
converted into KW HOUR (KWH counter 32bit) by LogicLinx to be passed to the DNP master. Then
"KWH counter 32bit" is converted into two 16-bit counters (KWH counter 16bit MSB and KWH
counter 16bit LSB) to be passed to the MODBUS master.
