GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
Appendix B: iBox Kit Default
Configurations
When shipped as part of an iBox Kit, the iBox COM port default configurations are set to one of the
following:
iBox (IBOX-BSC
1
)
Configuration Details Comments
DNP DPA
iBox DNP 3.0 Master Address: 10
iBox DNP 3.0 Slave Address: 1
Communication Port: COM1
Baud Rate: 9600
Communication Type: RS-232
Refer to point map tables for more detail.
Modbus DPA
Modbus Address: 1
Communication Port: COM2
Baud Rate: 9600
Communication Type: RS-232
Refer to point map tables for more detail.
DNP DCA
iBox DNP 3.0 Master Address: 10
iBox DNP 3.0 Slave Address: 1
Communication Port: COM3
Baud Rate: 9600
Communication Type: RS-232
The DNP DCA is configured to poll an iBox. If
you connect COM3 to COM1, you can see the
DNP DCA polling the DNP DPA.
WESMAINT
User Name: westronic
Password: rd
Control Password: control
1
Name of the device within the SGConfig sample project
