GE iBox User Manual

GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
143
Appendix A: Technical Specifications
iBox
Power
Requirements
Power Supply Input Options
20-60 Vdc
Power Consumption
7 Watts (maximum)
Inrush Current
Less than 0.5A peak
Power Supply Protection
Input fuse
Reverse polarity protection provided
Communi-
cation Ports
Maintenance Port
WESMAINT DB-9-F, EIA 232 @ 9600 bps
Standard Serial Communication
Ports (3)
DB-9-F, EIA 232/485 up to 38400 bps (concurrently)
Software configurable
Jumper selectable (JP3) Radio Key output on Port 1
36 Vdc max., 3 A peak max., 0.1 sec ON, 10% duty
cycle
UTC Time Port
(in place of one serial port)
DB-9-F, EIA 232 Port 2
Digital Inputs
General
Up to eight bipolar optically isolated (2000 V
rms
)
Burden
From 1.9 mA to 5.5 mA
max. power dissipation is 0.5 W per input
Wetting Options
External wetting - for all input options
Modes of operation:
Dry contact and voltage sense
24 Vdc, 48 Vdc, and 110/125 Vdc
Continued on next page
