GE iBox User Manual

iBox/iBox Kit
Installation and Maintenance Guide
GE Grid Solutions
144
994-0047-5.10-4 GE Information
Technical Specifications – iBox, continued
Digital
Outputs
General
Up to four relay outputs: 4 Trip/Close pairs or 2
Trip/Close pairs and 2 Form A contacts
Security features
Separate Master Trip and Master Close relays
Single point of failure integrity, select-before-
operate (SBO) functionality. Remote/Local jumper
JP2.
Control Voltage
External
Switching Characteristics
35 W breaking @ 150 Vdc
180 W breaking @ 30 Vdc
Maximum Carrying Current
6 A
Size and
Environment
Dimensions
Width (of Mounting
Panel)
28 cm (11 inch)
Height 19 cm (7.5 inch)
Depth 4.5 cm (1.75 inch)
Weight
1 kg (2.2 lb) maximum
Operating Temperature
-40° to +80°C, may exceed EN61010-1 metal
enclosure temperature of +70° C at ambient
temperature of +60°C.
Storage Temperature
-40° to +90°C
Humidity Rating
0 to 95% relative humidity, non-condensing
Operating Altitude
0 to 2000 meters
Environmental Rating
IP20
Installation (Overvoltage)
Category
CAT II EN61010-1
Note: Must be installed in an overall protective
enclosure and/or a protective environment unless
the power supply terminals have a protective cover
installed
Pollution Degree
2
IEC 68-2-1
Cold
IEC 68-2-2
Dry heat
IEC 68-2-6
Vibration
IEC 68-2-30
Damp heat, cyclic (12+12-hour cycle)
MTBF
> 74000 hours @ 40°C
Note: Increased operating temperature decreases
MTBF of the device
Continued on next page
