Technical Specifications – iBox, continued
EMI/EMC
Compliance
CISPR11
Limits and methods of measurement of
electromagnetic disturbance characteristics of
industrial, scientific and medical (ISM) radio-
frequency equipment.
EN61000-4-2
Immunity Test
EN61000-4-3
Radiated, radio-frequency, electromagnetic field
immunity Test
EN61000-4-4
Electrical Fast Transient/Burst Immunity Test
EN61000-4-5
Surge Immunity Test
EN61000-4-6
Immunity to conducted disturbances induced by
radio-frequency fields
EN 61000-4-12
Damped Oscillatory Wave Immunity Test (100 kHz/1
MHz)
EN 61010-1
Safety Requirements For Electrical Equipment For
Measurement, Control and Laboratory Use - Part 1:
General Requirements.
EN60255-5
Dielectric Test
Impulse Voltage Test
Insulation Resistance
EN61000-4-16
Test for Immunity to Conducted, Common Mode
Disturbances in the Frequency Range 0 Hz to 150
kHz (steady state frequency)
IEEE C37.90.1-1989
SWC capability
Field
Terminations
& Wiring
Digital Outputs
250 V rated compression termination consisting of a
header and removable plugs suitable for 12 – 24
AWG wire rated for 6A/150V
Power Supply Inputs
250 V rated compression termination consisting of a
header and removable plugs suitable for 12 – 24
AWG wire 0.5A/60V
Digital Inputs
250 V rated compression termination consisting of a
header and removable plugs suitable for 12 – 24
AWG wire 0.01A/150V
Protective Earth Terminal
#10 fastener
Note: Ground wire must be the largest gauge of all
wires used for field termination. A green and
yellow 12 AWG wire is recommended.
