iBox/iBox Kit
Installation and Maintenance Guide
GE Grid Solutions
994-0047-5.10-4 GE Information
Continued on next page
Familiarization, continued
Control
Outputs
The iBox provides the following control outputs:
• Four Trip/Close pairs, or two Trip/Close pairs and two Form A contacts.
• Separate Master Trip and Master Close relays
• Security features:
− Protection against erroneous operation due to single point of failure
− Select-before-operate (SBO) functionality
• 35
W breaking @ 125
VDC, 180
W breaking @ 30
VDC
• 6
A current handling capability
To Next Page
