iBox/iBox Kit
Installation and Maintenance Guide
GE Grid Solutions
994-0047-5.10-4 GE Information
Configuring Application Firmware
Overview
The iBox uses the D25 Plant I/O Subsystem (P097) Data Collection Application to
configure the digital inputs. Configure the iBox Plant I/O before you configure the
points in the System Point Database application.
Procedure:
Digital Input
Configuration
To configure the DC digital inputs:
Step Action
1
Configuring the iBox PPP Driver and Internet Data
2
Double-click the D25 Plant I/O Subsystem icon.
Result: The D25 Plant I/O for iBox dialog box appears.
3
Double-click the DC Configuration icon.
Result: The D25 DC Configuration for iBox dialog box appears.
4
On the General tab, select the type of digital input board from the First
Digital Input board list. Select one of:
• C: iBox 8 channels, 24 V wetting
• D: iBox 8 channels, 48 V wetting
• E: iBox 8 channels, 125 V wetting
The other board settings are preset.
Result: The letter in the Device Code changes to match your selection.
Note: Refer to the on-line help in SGConfig for details on configuring
the I/O Configuration and Advanced tabs.
Other
Application
Configuration
Configure your other applications before continuing to install the iBox. Each
application has its own configuration process. Refer to the documentation for your
specific applications for configuration information.
