TRANSFIX Installation Manual 34 TRANSFIXFAMILYIM Rev 3 18-Jan-16
Appendix A Installation Tools and Supplies
The tools and supplies for a product installation are listed below. If GE performs the
installation, the GE installation engineer will provide these items:
GE-supplied Items A.1
9
/
16
in. Combination wrench (must be imperial
9
/
16
in.)
30 cm (12 in.) Adjustable wrench
35 – 40 cm (14 in.) Pipe wrench
1
/
8
flat blade screwdriver
¼ in. flat blade screwdriver
Non-metallic tape measure
Level capable of indicating plumb and level within 5 degrees
Permanent marker (fine tip)
22 – 14 Gauge wire cutter/stripper
Small diagonal cutting pliers
Quality vacuum pump with approximately 3 ft of clear ¼ in. tubing fitted with a ¼ in.
compression fitting at the end of the tubing
12 mm (½ in.) width PTFE pipe-sealing tape or PTFE pipe compound
30 cm (12 in.) Nylon UV-resistant cable ties
Laptop computer for commissioning the product and running the TRANSCOM software for
downloading and interpreting the results of the gas analysis. Minimum specification:
Windows® 2000 or Windows® XP operating system, PII 400 MHz processor, 128 MB of RAM
and 1.2 GB hard drive space, 28.8 Kbps modem or faster and USB 1.1 or faster.
A.2 Customer-supplied Items
The following tools and supplies are needed on site to secure the mounting stand (if
used), tighten the 2 in. pipe fittings (if used) and complete the installation. GE is unable to
bring the following items due to size and weight restrictions, so the customer should
provide them.
12 mm (½ in.) capacity hammer drill with 9.5 mm (
3
/
8
in.) masonry bit
36 in. pipe wrench if large fittings are used to provide oil to the product
Scaffolding, lift or approved platform to obtain access to valves (if needed)
Suitable vessel to collect at least 4 litres of waste oil during the commissioning process
M8 threaded fasteners with a recommended minimum length of 80 mm for the concrete pad
