Table I—1: List of terminals
Terminal
Signal
Description
PSTN Interface
1
TIP
PSTN interface
2
RING
Digital outputs
Note: Alarm Relay Max Ratings: 3 A at 250 V AC, 200 mA at 125 V DC or 3 A at 30 V DC.
3
NO
Service Alarm
4
COM
5
NC
Spacer
6
NO
Watchdog Alarm
Note: The default condition is NO when the product is powered on.
7
COM
8
NC
Spacer
9
NO
Relay 2
10
COM
11
NC
Spacer
12
NO
Relay 3
13
COM
14
NC
Spacer
15
NO
Relay 4
16
COM
17
NC
Spacer
18
NO
Relay 5
19
COM
20
NC
Spacer
21
NO
Relay 6
22
COM
23
NC
Spacer
24
NO
Relay 7
25
COM
26
NC
Spacer
Digital Inputs
Note: Digital inputs have a maximum voltage level of 12 V. The switching voltage input level is
approximately 2.5 V. The three digital channels are separate from each other. Digital inputs are not
available through PERCEPTION software, but can be read through the Modbus protocol.
27
DIG IN 1+
Digital Input channel 1, positive
28
DIG IN 1-
Digital Input channel 1, negative
29
DIG IN 2+
Digital Input channel 2, positive
30
DIG IN 2-
Digital Input channel 2, negative
31
DIG IN 3+
Digital Input channel 3, positive
32
DIG IN 3-
Digital Input channel 3, negative
Spacer
Analog Inputs
33
ANALOG IN A
Analog input - Load sensor, positive
34
ANALOG IN B
Analog input - Load sensor, negative
Spacer
