MA-001 – TRANSFIX-family Installation Manual – Rev 3.0 18-Jan-16 Page 37 of 55
C.2 Transformer Details
Make: Year: Years in Service:
Type:
Conservator Nitrogen Blanketed Other:
MVA Rating:
CT ratio:
Condition of Desiccant:
Attach several photos showing the transformer and surrounding area
Attach all available DGA data
Total Dissolved Gas: ___________ ppm (sum of all measured gases)
Please describe (or attach separately) details of any major maintenance actions, such
as a rebuild, vacuum degassing or filtering etc.
C.2.1 Transformer Oil
Oil Capacity: (in gallons) (in litres)
Manufacturer: Type:
Certified PCB free: Yes No
Temperature range at oil supply valve: High °C Low °C
Temperature range at oil return valve: High °C Low °C
C.2.2 Transformer Nitrogen Blanket (if applicable)
How frequently does the nitrogen bottle need to be changed?
Years Months
Headspace Pressure: psi (kPa, bar)
