KTD-405/405A/405-2D Keypad
Quick Guide
13
System defaults
Programming settings Defaults Range
Keypad address 99 1 to 254
KB3 PTZ protocol No Yes / No
Enable remote programming Yes Yes / No
Keypad title Blank 0 to 14 characters
Keypad lockout priority 0 = Off 0 to 9 levels
Lowest user programming 58 1 to 128
Program soft keys No Yes / No
Change access code No Yes / No
Baud rate (KBPS) 0 = Default 0, 9, 19, 38
System controller No Yes / No
Operating mode Digiplex Digiplex / Zone
System size (cameras) 511 1 to 1599
System size (monitors) 64 1 to 128
System size (multiplexers) 32 0 to 254
System size (DSR/VCR) 32 0 to 32
System size (presets) 63 0 to 127
Set access to cameras None set Level 0 to 9 per camera
Set access to monitors None set Level 0 to 9 per monitor
Set access to DSR/VCR None set Level 0 to 9 per DSR/VCR
Set access to multiplexers None set Level 0 to 9 per multiplexer
Monitor offset 0 0 to 63
Annunciation No Yes / No
