GE KTD-405 Quick Guide

KTD-405/405A/405-2D Keypad
Quick Guide
8
DVR recorded event search
To initiate a search, press . The Disk Analysis screen appears on the monitor.
Disk Analysis screen
The default view shows the entire time
period currently saved on the disk.
To scroll forward or backward in disk time,
push the joystick up or down, or press esc
+ or esc + . The black indicator arrows
move left and right to show the selected
time.
To view shorter or longer spans of time,
push the joystick left or right, or press  or
. There are four view levels.
To view playback of the currently selected
time period, press  .
To specify search parameters, press .
The Motion Search menu appears.
Motion Search menu
At the Motion Search menu, select a time
parameter.
To navigate through the options, push up
of down on the joystick, or press esc +or
esc +.
To select an option push left or right on the
joystick, or press esc + or esc + .
To initiate a search on a selected preset
time parameter, press  . Playback begins
and the Motion Search Setup screen
appears.
To customize a time period to search,
select custom and press  . The Custom
Time menu appears.
To apply filters to a custom or preset time
parameter, press . The Search Filters
menu appears.
Custom Time menu
At the Custom Time menu, customize a
time period to search.
To navigate through the date and time
fields, push left or right on the joystick, or
press esc + or esc + .
To change settings for each option, press
esc + or esc +.
To accept the customized time settings,
press  . Playback begins and the Motion
Search Setup screen appears.
Note: To exit the search function, continue
pressing esc until all search menus
disappear from the monitor.
