KTD-405/405A/405-2D Keypad
Quick Guide
7
DVR operation
DVR selection in zone mode
To select a DVR when in zone mode, do the
following:
1. Press zone.
2. Enter the zone number.
Note: See Zone mode on page 3.
DVR selection in Digiplex mode
To select a DVR when in Digiplex mode, do
the following:
1. Press zone. The keypad switches to
hybrid zone mode.
2. Enter the DVR/zone number.
Note: See Digiplex mode and Hybrid zone
mode on page 4.
Multiscreen views
To call up multiscreen views on a Triplex or
DVR (zone or hybrid zone mode only), do
one of the following:
•Press view, <number keys 1 to 9>; or
•Press view, 5 repeatedly to step
through the available views.
To call up multiscreen views on other DVR
models and multiplexers, press view
repeatedly to step through the available
views.
System information. You must know
the DVR/zone number to call a DVR from
the keypad. If you don’t know that
information, contact your system
installer, integrator, or administrator and
record that information on the System
information table on page 16.
Hybrid zone mode. Press esc to return
from hybrid zone mode to Digiplex
mode. You do not have PTZ control of
cameras in hybrid zone mode.
Error. The keypad beeps when you enter
a zone number that does not exist or if
the keypad is not communicating with
the DVR.
