KTD-405/KTD-405A/KTD-405-2D Controller Keypad

User Manual

Back panel connections

KTD-405/KTD-405-2D connections

Adhere to all installation guidelines while making connections, including your local codes and those provided

in Installation guidelines on page 8.

Figure 5. KTD-405/KTD-405-2D back panel connections

RS-232 programming port (future use) RJ45 control cable (GE equipment

uses two different RJ45 cables. You

must use the RJ45 cable provided

with the unit.)

I/O box

RS-485 and RS-422 in/out Power supply

RS-485 termination switch Power cord

A D E

B F

C G
