GE LOGIQ F6 Service Manual

GE LOGIQ F SERIES
DIRECTION 5446617-100, REVISION 10 BASIC SERVICE MANUAL
Chapter 4 - Functional Checks 4 - 15
4-3-7 M Mode Controls
4-3-7-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-21, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already).
Figure 4-12 Controls available in M Mode
Figure 4-13 M Mode Screen Picture Example
M/D Cursor
M-Mode Menu
M-Mode/Gain
TGC
