GE LOGIQ F SERIES
DIRECTION 5446617-100, REVISION 10 BASIC SERVICE MANUAL
Chapter 4 - Functional Checks 4 - 17
4-3-8 Doppler Mode Checks
4-3-8-1 Preparations
1.) Connect one of the probes listed in 3-6-6 "Available Probes" on page 3-21, in Chapter 3 Installation
to the System probe connector.
2.) Turn ON the scanner (if it isn’t turned on already).
Figure 4-14 Controls available in Doppler Mode
Figure 4-15 Doppler Mode Screen Picture Example
M/D Cursor
Primary Menu
PW-Mode/Gain
Set/B Pause Cursor
TGC
To Next Page
