Peripherals Installation
LOGIQ V3/V5/V5 Expert – Basic Service Manual 3-33
5726264-100 English Rev.8
3-7-3-3 Sony UP-D25MD Printer Installation
3-7-3-3-1 Tools
No special tools needed.
3-7-3-3-2 Manpower
One person 5 min.
3-7-3-3-3 Preparations
1. Unpack the Sony UP-D25MD Printer.
2. Ensure no physical damage.
3-7-3-3-4 Installation Procedure
1. Place the device in a suitable place.
2. Connect the USB Cable on the Printer.
3. Connect the power cord with the AC output in the wall outlet,
then turn on the printer.
4. Connect USB cable to LOGIQ V3/V5/V5 Expert isolated
USB port.
Figure 3-20. Color Printer connection
5. Refer to the Connectivity configure steps of 3-7-3-1 ‘Sony
UP-D711MD Printer Installation’ on page 3-29.
