System Setup
3-16 LOGIQ V3/V5/V5 Expert – Basic Service Manual
5726264-100 English Rev.8
3-5-4 Electrical specifications
3-5-4-1 Verification of the system’s voltage setting
Verify that the mains voltage specified for the LOGIQ V3/V5/V5
Expert is available on-site.
Refer to the latest revision of the Basic User Manual for a full list
of product labels prior to serving the system.
3-5-4-2 Electrical specifications for LOGIQ V3/V5/V5 Expert
In the table below, the electrical specifications for LOGIQ V3/V5/
V5 Expert includes monitor and on board peripherals.
Connecting a LOGIQ V3/V5/V5 Expert to the wrong voltage
level will most likely destroy it.
Table 3-4: Electrical specifications for LOGIQ V3/V5/V5 Expert
Part
Number
Description Voltage Tolerances
Power
consumntion
Frequenc
y
5715379 LOGIQ V3
100-240V ±10% Max.300VA 50/60 Hz5715380 LOGIQ V5
5718054 LOGIQ V5 EXPERT
