System Setup
3-22 LOGIQ V3/V5/V5 Expert – Basic Service Manual
5726264-100 English Rev.8
3-6-2-1 User Configurable Key installation(continued)
TVI, LOGIQ View or 3D/4D, If any of them is installed, please
replace the blank key cap according to the assigned software
function.
Figure 3-5. Replace Key Cap
There is a key reserved for CWD function, replace the blank
key cap for CWD option if CWD option installed.
Figure 3-6. CWD Key Cap
