GE lp33 20 series User Manual

Critical Power
Modifications reserved
Page 35/43
GE_UPS_ISG_LPS_3UL_20K_30K_2US_V010.docx
Installation Guide LP33 Series 20 & 30 UL S2
5 CUSTOMER INTERFACE
Fig. 5-1 Slot connectivity
LP33 Series 20 & 30 is supplied by a standard Serial Port J27 - RS232 (see Section 5.1) and a Relay
Card (see Section 5.2).
List of possible connectivity configurations on LP33 Series 20 & 30
Slot 1 – J4
Slot 2 – J3
Slot 3 – J5
Slot 1 – J4 + Slot 2 – J3
Relay Card (standard)
-
-
-
Relay Card (standard)
Advanced SNMP Card
(optional)
-
-
Relay Card (standard)
Advanced SNMP Card
(optional)
Advanced SNMP Card
(optional)
-
-
-
-
Customer Interface (optional)
-
-
Advanced SNMP Card
(optional)
Customer Interface (optional)
LPS33U_020-030_S2_UPS connectivity_01
Q2
Q1
RELAY CARD
SLOT 1 (J4)
J27 - RS232
SLOT 2 (J3)
SLOT 3 (J5)
