4–26 350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL
A3 RECORDS CHAPTER 4: ACTUAL VALUES
0xDD04 LE 13 DPO
0xDD41 LE 14 PKP
0xDD42 LE 14 OP
0xDD44 LE 14 DPO
0xDD81 LE 15 PKP
0xDD82 LE 15 OP
0xDD84 LE 15 DPO
0xDDC1 LE 16 PKP
0xDDC2 LE 16 OP
0xDDC4 LE 16 DPO
0xE042 Therm O/L Blck OP
0xE044 Therm O/L Blck Off
0xE182 Output Relay 1 BLK
0xE184 Relay 1 BLK Off
0xE1C2 Output Relay 2 BLK
0xE1C4 Relay 2 BLK Off
0xE882 Group Change Blk
0xE884 Grp Change Blk DPO
0xEB02 AR Block
0xEB04 AR Block DPO
0xEE82 CLP Ph IOC1 BLK
0xEE84 CLP Ph IOC1 BLKDPO
0xEEC2 CLP Ph IOC2 BLK
0xEEC4 CLP Ph IOC2 BLKDPO
0xEF02 CLPNtrlIOC1 BLK
0xEF04 CLPNtrlIOC1 BLKDPO
0xEF42 CLPNtrlIOC2 BLK
0xEF44 CLPNtrlIOC2 BLKDPO
0xEF82 CLP GndIOC1 BLK
0xEF84 CLP GndIOC1 BLKDPO
0xEFC2 CLP GndIOC2 BLK
0xEFC4 CLP GndIOC2 BLKDPO
0xF002 Ph IOC1 Block
0xF004 Ph IOC1 Block DPO
0xF042 Ntrl IOC1 Block
0xF044 Ntrl IOC1 Blk DPO
0xF082 Gnd IOC1 Block
0xF084 Gnd IOC1 Block DPO
0xF0C2 Ph TOC1 Block
0xF0C4 Ph TOC1 Block DPO
0xF102 Ntrl TOC1 Block
0xF104 Ntrl TOC1 BlockDPO
0xF142 Gnd TOC1 Block
0xF144 Gnd TOC1 Block DPO
0xF182 Ph IOC2 Block
0xF184 Ph IOC2 Block DPO
0xF1C2 Ntrl IOC2 Block
