CHAPTER 6: SETPOINTS S1 RELAY SETUP
350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 6–23
0xB081 Gnd IOC1 Alarm PKP
0xB082 Gnd IOC1 Alarm OP
0xB084 Gnd IOC1 Alarm DPO
0xB0C1 Ph TOC1 Alarm PKP
0xB0C2 Ph TOC1 Alarm OP
0xB0C4 Ph TOC1 Alarm DPO
0xB0C9 Ph A TOC1 Alrm PKP
0xB0CA Ph A TOC1 Alrm OP
0xB0CC Ph A TOC1 Alrm DPO
0xB0D1 Ph B TOC1 Alrm PKP
0xB0D2 Ph B TOC1 Alrm OP
0xB0D4 Ph B TOC1 Alrm DPO
0xB0E1 Ph C TOC1 Alrm PKP
0xB0E2 Ph C TOC1 Alrm OP
0xB0E4 Ph C TOC1 Alrm DPO
0xB101 Ntrl TOC1 Alrm PKP
0xB102 Ntrl TOC1 Alrm OP
0xB104 Ntrl TOC1 Alrm DPO
0xB141 Gnd TOC1 Alarm PKP
0xB142 Gnd TOC1 Alarm OP
0xB144 Gnd TOC1 Alarm DPO
0xB181 Ph IOC2 Alarm PKP
0xB182 Ph IOC2 Alarm OP
0xB184 Ph IOC2 Alarm DPO
0xB189 Ph A IOC2 Alrm PKP
0xB18A Ph A IOC2 Alrm OP
0xB18C Ph A IOC2 Alrm DPO
0xB191 Ph B IOC2 Alrm PKP
0xB192 Ph B IOC2 Alrm OP
0xB194 Ph B IOC2 Alrm DPO
0xB1A1 Ph C IOC2 Alrm PKP
0xB1A2 Ph C IOC2 Alrm OP
0xB1A4 Ph C IOC2 Alrm DPO
0xB1C1 Ntrl IOC2 Alrm PKP
0xB1C2 Ntrl IOC2 Alrm OP
0xB1C4 Ntrl IOC2 Alrm DPO
0xB201 Gnd IOC2 Alarm PKP
0xB202 Gnd IOC2 Alarm OP
0xB204 Gnd IOC2 Alarm DPO
0xB301 SGnd TOC1 Alrm PKP
0xB302 SGnd TOC1 Alrm OP
0xB304 SGnd TOC1 Alrm DPO
0xB342 NtrlDir RevAlm OP
0xB344 NtrlDir RevAlm DPO
0xB382 GndDir RevAlm OP
0xB384 GndDir RevAlm DPO
0xB3C1 NegSeq OV Alrm PKP
