GE Multilin N60 Network Stability and Synchrophasor Measurement System B-81
APPENDIX B B.4 MEMORY MAPPING
B
83 Ground Time Overcurrent 4
84 Ground Time Overcurrent 5
85 Ground Time Overcurrent 6
86 Restricted Ground Fault 1
87 Restricted Ground Fault 2
88 Restricted Ground Fault 3
89 Restricted Ground Fault 4
90 Restricted Ground Fault 5
91 Restricted Ground Fault 6
96 Negative Sequence Instantaneous Overcurrent 1
97 Negative Sequence Instantaneous Overcurrent 2
98 Fast Dist
101 Opposite Phase Rotation
102 8-bit Comparator 1
103 8-bit Comparator 2
104 8-bit Comparator 3
105 8-bit Comparator 4
106 8-bit Comparator 5
107 8-bit Comparator 6
112 Negative Sequence Time Overcurrent 1
113 Negative Sequence Time Overcurrent 2
120 Negative Sequence Overvoltage 1
121 Negative Sequence Overvoltage 2
122 Negative Sequence Overvoltage 3
125 Generator Unbalance
128 High Impedance Fault Detection (Hi-Z)
129 Bus Zone 1
130 Bus Zone 2
131 Bus Zone 3
132 Bus Zone 4
133 Bus Zone 1
134 Bus Zone 2
140 Auxiliary Undervoltage 1
141 Auxiliary Undervoltage 2
142 Auxiliary Undervoltage 3
144 Phase Undervoltage 1
145 Phase Undervoltage 2
146 Phase Undervoltage 3
149 Auxiliary Overvoltage 2
150 Auxiliary Overvoltage 3
151 Phase Overvoltage 1
152 Phase Overvoltage 2
153 Phase Overvoltage 3
154 Compensated Overvoltage 1
156 Neutral Overvoltage 1
157 Neutral Overvoltage 2
158 Neutral Overvoltage 3
160 Phase Distance Zone 1
161 Phase Distance Zone 2
162 Phase Distance Zone 3
163 Phase Distance Zone 4
164 Phase Distance Zone 5
168 Line Pickup
Bitmask Element
172 Ground Distance Zone 1
173 Ground Distance Zone 2
174 Ground Distance Zone 3
175 Ground Distance Zone 4
176 Ground Distance Zone 5
180 Load Encroachment
184 DUTT
185 PUTT Pilot Scheme
186 POTT
187 Hybrid POTT
188 Block Scheme
190 Power Swing Detect
192 Data Trig 1
193 Data Trig 2
194 Data Trig 3
195 Data Trig 4
200 Async
202 Transformer Hottest Spot
203 Transformer Aging Factor
204 Transformer Loss of Life
208 Transformer Instantaneous
209 Transformer Percent Differential
210 Volt per Hertz 1
211 Volt per Hertz 2
214 Sensitive Directional Power 1
215 Sensitive Directional Power 2
221 100% Stator Ground
222 Split Phase Protection
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
228 SRC5 VT Fuse Failure
229 SRC6 VT Fuse Failure
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
236 SRC5 50DD (Disturbance Detection)
237 SRC6 50DD (Disturbance Detection)
240 87L Current Differential
241 87L Diff
242 Open Pole Detector
244 50DD Disturbance Detector
245 Continuous Monitor
247 CT Trouble 1
248 CT Trouble 2
249 CT Trouble 3
250 CT Trouble 4
251 CT Trouble 1
252 CT Trouble 2
254 87L Trip (Current Differential Trip)
255 Stub Bus
