GE NetworX NX-6 User Manual

Page 17
LOCATION 23 PARTITION 1
FEATURE AND REPORT SELECTIONS
3 segments, feature selection
Location 23 is used to enable certain features that can be accessed or are visible to the user from the keypad of the
system. In addition, certain communicator reports are enabled in location 23. Each of these features can be enabled by
partition. For additional partition information see locations 88-91 on page 27. If the feature selection location for
any partition is left blank, that partition will use this location for the feature selection. This location contains 3
segments of 8 features each. (See the definitions beginning on page 3.)
Segment 1
â On enables the Quick Arm feature.
ã On enables the Re-exit feature.
ä On enables the Automatic Bypass feature.
å On enables the Silent Keypad Panic feature (overrides the audible panic selection).
æ On enables the Audible Keypad Panic feature.
ç On enables the Keypad Aux 1 feature (FIRE).
è On enables the Keypad Aux 2 feature (MEDICAL).
é On enables the Keypad Multiple Code Attempt Tamper feature.
Segment 2
â On enables the LED Extinguish feature.
ã On enables the Require Code for Bypassing feature.
ä On enables the Zone Bypassed Sounder Alert feature.
å On enables the AC Power/Low Battery Sounder Alert feature.
æ On enables Bypass toggle.
ç On enables Silent Auto Arm.
è On enables the Automatic Instant feature.
é Reserved.
Segment 3
â On enables Opening and Closing reports.
ã On enables Zone Bypass reporting.
ä On enables Zone Restore reporting.
å On enables Zone Trouble reporting.
æ On enables Zone Tamper reporting.
ç On enables the Cancel reporting.
è On enables the Recent Closing report.
é On enables the Exit Error report.
LOCATION 24
ENTRY / EXIT TIMERS 4 segments, numerical data
Location 24 is used to program the Entry/Exit times. There are 2 separate Entry/Exit times.
Segment 1
Entry time 1 This is the entry time that will be used when a delay 1 zone type initiates an
entry delay. Valid entries are 30-255 seconds.
Segment 2
Exit time 1
This is the exit time that will be used for all zones desi
g
nated as delay 1. Valid
entries are 45-255 seconds.
Segment 3
Entry time 2
This is the entry time that will be used when a delay 2 zone type initiates an
entry delay. Valid entries are 30-255 seconds.
Segment 4
Exit time 2
This is the exit time that will be used for all zones designated as delay 2. Valid
entries are 45-255 seconds.
NOTE: The combined Entry Delay (loc 24) and Dial Delay (loc 40) must not exceed 1 minute for SIA CP-01
requirements.

GE NetworX NX-6 Specifications

Operating Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Loop Specifications

loop resistance for standard loop	300 Ohms Maximum
loop resistance for 2-wire smokes	30 Ohms Maximum
loop response	500mS

Operating Environment

operating temperature	32 to 120 degrees F

LED Keypad Specifications

led keypad current draw	130 mA max.
led keypad dimensions width	6.4"
led keypad dimensions height	4.0"
led keypad dimensions depth	1.1"

NX-148E LCD Keypad Specifications

nx-148e lcd keypad current draw	110 mA max.
nx-148e lcd keypad dimensions width	6.4"
nx-148e lcd keypad dimensions height	5.3"
nx-148e lcd keypad dimensions depth	1.0"

Enclosure and Shipping

metal enclosure dimension width	11.25"
metal enclosure dimension height	11.25"
metal enclosure dimension depth	3.50"
shipping weight	9 lbs.
