LOCATION 47 AUXILIARY OUTPUT #1, EVENT AND TIME 2 segments, numerical data
Segment 1
Use Table 2.1 to select the event that will activate Auxiliary Output 1.
Segment 2
Program the timing from 0-255 (minutes or seconds, depending on data programmed in
Segment 1, Location 46). Programming a "0" makes the output follow the event.
LOCATION 48
AUXILIARY OUTPUT #2, EVENT AND TIME
2 segments, numerical data
Segment 1
Use Table 2.1 to select the event that will activate Auxiliary Output 2.
Segment 2
Program the timing from 0-255 (minutes or seconds, depending on data programmed in
Segment 2, Location 46). Programming a "0" makes the output follow the event.
LOCATION 49
AUXILIARY OUTPUT #3, EVENT AND TIME
2 segments, numerical data
Segment 1
Use Table 2.1 to select the event that will activate Auxiliary Output 3.
Segment 2
Program the timing from 0-255 (minutes or seconds, depending on data programmed in
Segment 3, Location 46). Programming a "0" makes the output follow the event.
LOCATION 50
AUXILIARY OUTPUT #4, EVENT AND TIME
2 segments, numerical data
Segment 1
Use Table 2.1 to select the event that will activate Auxiliary Output 4.
Segment 2
Program the timing from 0-255 (minutes or seconds, depending on data programmed in
Segment 4, Location 46). Programming a "0" makes the output follow the event.
AUXILIARY OUTPUT EVENT SELECTION
Table 2.1
DATA EVENT DATA EVENT DATA EVENT
0 / Burglary Alarm 19 Exit 38 Download In Process
1 / Fire Alarm 20 Entry or Exit 39 Smoke Power
2 / 24 Hour Alarm 21 Armed State 40 Short Circuit (Over-
current)
3 / Trouble Alarm 22 Disarmed State 41 Box Tamper
4 / Tamper Alarm 23 Ready 42 Siren Tamper
5 Yelping Siren (Burglary) 24 Not Ready 43 Any Open
6 Temporal Siren (Fire) 25 Fire 44 Any Short
7 Any Siren 26 Fire Trouble 45 Any Fault (Open/ Short on
Non-Fire Zone)
8 Any Bypass 27 Chime 46 / Any Alarm
9 AC Fail 28 / Expander Trouble 47 Beeping Keypad
10 Low Battery 29 Dynamic Battery Test Time 48 / Code Entry (See note)
11 / Duress 30 Open Period 49 ˜ / Key FOB Function 1
12 / Aux 1 Keypad Zone 31 Closed Period 50 ˜ / Key FOB Function 2
13 /
Aux 2 Keypad Zone
32 Listen-In 51 / Always On
14 / Panic Keypad Zone 33 Line Seizure 52 Flashing in Alarm
15 Keypad Tamper 34 Ground Start 53 Armed AWAY
16 / Autotest 35 Fail To Communicate 54 Armed STAY
17 Alarm Memory 36 Telephone Line Fault
18 Entry 37 Program Mode
˜ Events 49 & 50 require NX-408E, NX-416E, or NX-448E wireless receivers to operate.
/ If set to follow condition, these events will be 1 second.
NOTES: When Event 48 is programmed, it is possible to program a user code's authorization to select which output(s) a
particular code will activate. When LED 8 is on for an authorization, then LEDs 1- 4 correspond to that code activating
outputs 1 - 4 respectively. (See programming the LED keypads on page 8.)
