GE NetworX NX-6 User Manual

Page 33
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
AUXILIARY OUTPUT #2, EVENT & TIME
48 22
Segment #1: Program the event number for output #2
Segment #2: Program the timing for output #2
1=Fire alarm
10 seconds
___
___
AUXILIARY OUTPUT #3, EVENT & TIME
49 22
Segment #1: Program the event number for output #3
Segment #2: Program the timing for output #3
2= 24 Hour Alarm
10 seconds
___
___
AUXILIARY OUTPUT #4, EVENT & TIME
50 22
Segment #1: Program the event number for output #4
Segment #2: Program the timing for output #4
39 - Smoke Power
0=Follow condition
___
___
AUTOTEST CONTROL
51 23
Segment #1: Program a "1" if the interval is hours, a "0" if
in days. Program a A2" to suppress the daily test or a A3" to
suppress the hourly test.
Segment #2: Program the autotest interval from 1-255
days or hours.
Segment #3: Program the autotest report in 24-hour time
format.
Segment #4: Program the autotest report time, minutes
after the hour.
0
24
2
0
___
___
___
___
OPENING TIME 52 23
Segment #1: Program the hour of the opening time
Segment #2: Program the minutes after the hour of the
opening time
8
0
___
___
CLOSING TIME / AUTO ARMING TIME 53 23
Segment #1: Program the hour of the closing time / auto
arming time
Segment #2: Program the minutes after hour of closing/
auto arming time
20
0
DAYS OF THE WEEK EACH PARTITION IS OPEN Segments 1 - 2 Partition 1 -2 54 23
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Reserved
1
2
3
4
5
6
7
8
“ “
“ “
“ “
“ “
“ “
“ “
“ “
DAYS OF THE WEEK EACH PARTITION WILL "AUTO ARM" Segments 1 - 2 Partition 1 -2 55 23
Sunday
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Reserved
1
2
3
4
5
6
7
8
“ “
“ “
“ “
“ “
“ “
“ “
“ “
COMMUNICATOR CODES FOR SLOW SPEED FORMATS ONLY
RESTORE COMMUNICATOR CODE 56 24
Segment #1: Partition #1 Restore code
Segment #2: Partition #2 Restore code
0
0
___
___
BYPASS COMMUNICATOR CODE 57 24
Segment #1: Partition #1 Bypass code
Segment #2: Partition #2 Bypass code
0
0
___
___
TAMPER COMMUNICATOR CODE 58 24
Segment #1: Partition #1 Tamper Code
Segment #2: Partition #2 Tamper Code
0
0
___
___
TROUBLE COMMUNICATOR CODE 59 24
Segment #1: Partition #1 Trouble Code
Segment #2: Partition #2 Trouble Code
0
0
___
___

GE NetworX NX-6 Specifications

Operating Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Loop Specifications

loop resistance for standard loop	300 Ohms Maximum
loop resistance for 2-wire smokes	30 Ohms Maximum
loop response	500mS

Operating Environment

operating temperature	32 to 120 degrees F

LED Keypad Specifications

led keypad current draw	130 mA max.
led keypad dimensions width	6.4"
led keypad dimensions height	4.0"
led keypad dimensions depth	1.1"

NX-148E LCD Keypad Specifications

nx-148e lcd keypad current draw	110 mA max.
nx-148e lcd keypad dimensions width	6.4"
nx-148e lcd keypad dimensions height	5.3"
nx-148e lcd keypad dimensions depth	1.0"

Enclosure and Shipping

metal enclosure dimension width	11.25"
metal enclosure dimension height	11.25"
metal enclosure dimension depth	3.50"
shipping weight	9 lbs.
