Page

LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA

SENSOR LOW BATTERY COMMUNICATOR CODE 60 24

Segment #1: Partition #1 Sensor Low Battery Code

Segment #2: Partition #2 Sensor Low Battery Code

___

SENSOR MISSING COMMUNICATOR CODE 61 24

Segment #1: Partition #1 Sensor Missing Code

Segment #2: Partition #2 Sensor Missing Code

___

62 24 DURESS 0-0 __ __

63 24 AUXILIARY 1 0-0 __ __

64 24 AUXILIARY 2 0-0 __ __

65 25 KEYPAD PANIC 0-2 __ __

66 25 KEYPAD MULTIPLE CODE ENTRY TAMPER 0-0 __ __

67 25 BOX TAMPER / BOX TAMPER RESTORE 0-0-0-0 __ __ __ __

68 25 AC FAIL / AC RESTORE 0-0-0-0 __ __ __ __

69 25 LOW BATTERY / LOW BATTERY RESTORE 0-0-0-0 __ __ __ __

70 25 POWER SHORT / POWER SHORT RESTORE 0-0-0-0 __ __ __ __

71 25 BELL TAMPER / BELL TAMPER RESTORE 0-0-0-0 __ __ __ __

72 25 TELEPHONE LINE CUT / TELEPHONE LINE CUT RESTORE 0-0-0-0 __ __ __ __

74 25 EXPANDER TROUBLE / EXPANDER TROUBLE RESTORE 0-0-0-0 __ __ __ __

75 25 FAILURE TO COMMUNICATE 0-0 __ __

76 26 LOG FULL COMMUNICATOR CODE 0-0 __ __

OPENING COMMUNICATOR CODE 77 26

Segment #1: Partition #1 Opening Code

Segment #2: Partition #2 Opening Code

CLOSING COMMUNICATOR CODE 78 26

Segment #1: Partition #1 Closing Code

Segment #2: Partition #2 Closing Code

79 26 AUTOTEST COMMUNICATOR CODE 0-0 __ __

80 26 RECENT CLOSING AND EXIT ERROR 0-0 __ __

81 26 START PROGRAMMING / END PROGRAMMING 0-0-0-0 __ __ __ __

82 26 END DOWNLOAD 0-0-0-0 __ __ __ __

83 26 CANCEL COMMUNICATOR CODE 0 __

88 27 PARTITION 1, ACCOUNT CODE 10-10-10-10-10-10 __ __ __ __ __ __

89 27 PARTITION 2, ACCOUNT CODE 10-10-10-10-10-10 __ __ __ __ __ __

PARTITION 2, FEATURE SELECTION 90 27

1 -

2 -

3 -

4 -

5 -

6 -

7 -

8 -

Segment #1

Quick Arm “

Re-Exit “

Auto Bypass “

Silent Panic “

Audible Panic “

Auxiliary 1 “

Auxiliary 2 “

Multi Keypress Tamper “

Segment #2

LED extinguish enable “

Require user code for bypassing zones “

Bypass sounder alert “

AC power/low battery sounder alert “

Enables bypass toggle “

Enables silent auto arm “

Enables automatic instant “

Reserved

Segment #3

Open/Close “

Bypass “

Restore “

Trouble “

Tamper “

Cancel “

Recent Closing “

Exit Error “

PARTITION 2, ENTRY/EXIT TIMERS 91 27

Segment #1 (Entry Time #1)

Segment #2 (Exit Time #1)

Segment #3 (Entry Time #2)

Segment #4 (Exit Time #2)

Questions and Answers:

Need help?

Do you have a question about the GE NetworX NX-6 and is the answer not in the manual?

GE NetworX NX-6 Specifications

Operating Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Loop Specifications

loop resistance for standard loop	300 Ohms Maximum
loop resistance for 2-wire smokes	30 Ohms Maximum
loop response	500mS

Operating Environment

operating temperature	32 to 120 degrees F

LED Keypad Specifications

led keypad current draw	130 mA max.
led keypad dimensions width	6.4"
led keypad dimensions height	4.0"
led keypad dimensions depth	1.1"

NX-148E LCD Keypad Specifications

nx-148e lcd keypad current draw	110 mA max.
nx-148e lcd keypad dimensions width	6.4"
nx-148e lcd keypad dimensions height	5.3"
nx-148e lcd keypad dimensions depth	1.0"

Enclosure and Shipping
