GE NetworX NX-6 User Manual

Page 35
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
CUSTOMIZING ZONE TYPES (GROUPS)
110 28
ZONE TYPE 1 ALARM EVENT CODE
8 __
ZONE TYPE 1 CHARACTERISTIC SELECTION
Segment #1
1 - Fire (enable for fire zone) “
2 - 24 Hour (enable for non-fire 24 hour zone) “
3 - Keyswitch zone “
4 - Follower (enable for burg zones that are instant during non-entry times) “
5 - Delay 1 zone (enable to follow Timer #1 Entry/Exit) “
6 - Delay 2 zone (enable to follow Timer #2 Entry/Exit) “
7 - Interior (Enable for auto bypass or stay arming) “
8 - Local Only (enable if zone is not to be reported) “
Segment #2
1 - Keypad audible on alarm “
2 - Yelping siren on alarm “
3 - Temporal siren on alarm “
4 - Chime “
5 - Bypassable “
6 - Group Shunt “
7 - Force armable “
8 - Entry Guard “
111 28
Segment #3
1 - Reserved
2 - Double End of Line Tamper zone “
3 - Trouble zone (Day zone) “
4 - Cross Zone “
5 - Dialer Delay zone “
6 - Swinger zone “
7 - Restore reporting “
8 - Listen-In “
THE DEFAULTS LISTED IN THE ODD NUMBERED LOCATIONS BELOW REPRESENT THE THREE SEGMENTS OF EACH OF
THOSE LOCATIONS. USE THE THREE SEGMENT CHARTS FROM TABLE 3.1, PAGE 28 TO UNDERSTAND THESE DEFAULTS.
112 28 ZONE TYPE 2 ALARM EVENT CODE 2 ____
113
28
ZONE TYPE 2 CHARACTERISTIC SELECT 2-125-78 _____ _____ _____
114
28
ZONE TYPE 3 ALARM EVENT CODE 7 ____
115
28
ZONE TYPE 3 CHARACTERISTIC SELECT 5-1245-5678 _____ _____ _____
116
28
ZONE TYPE 4 ALARM EVENT CODE 5 ____
117
28
ZONE TYPE 4 CHARACTERISTIC SELECT 45-125-5678 _____ _____ _____
118
28
ZONE TYPE 5 ALARM EVENT CODE 5 ____
119
28
ZONE TYPE 5 CHARACTERISTIC SELECT 457-125-5678 _____ _____ _____
120
28
ZONE TYPE 6 ALARM EVENT CODE 4 ____
121
28
ZONE TYPE 6 CHARACTERISTIC SELECT 0-1245-5678 _____ _____ _____
122
28
ZONE TYPE 7 ALARM EVENT CODE 0 ____
123
28
ZONE TYPE 7 CHARACTERISTIC SELECT 2-0-78 _____ _____ _____
124
28
ZONE TYPE 8 ALARM EVENT CODE 1 ____
125
28
ZONE TYPE 8 CHARACTERISTIC SELECT 1-13-378 _____ _____ _____
126
28
ZONE TYPE 9 ALARM EVENT CODE 7 ____
127
28
ZONE TYPE 9 CHARACTERISTIC SELECT 6-1245-5678 _____ _____ _____
128
28
ZONE TYPE 10 ALARM EVENT CODE 2 ____
129
28
ZONE TYPE 10 CHARACTERISTIC SELECT 24-5-78 _____ _____ _____
130
28
ZONE TYPE 11 ALARM EVENT CODE 3 ____
131
28
ZONE TYPE 11 CHARACTERISTIC SELECT 3-0-0 _____ _____ _____
132
28
ZONE TYPE 12 ALARM EVENT CODE 5 ____

GE NetworX NX-6 Specifications

Operating Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Loop Specifications

loop resistance for standard loop	300 Ohms Maximum
loop resistance for 2-wire smokes	30 Ohms Maximum
loop response	500mS

Operating Environment

operating temperature	32 to 120 degrees F

LED Keypad Specifications

led keypad current draw	130 mA max.
led keypad dimensions width	6.4"
led keypad dimensions height	4.0"
led keypad dimensions depth	1.1"

NX-148E LCD Keypad Specifications

nx-148e lcd keypad current draw	110 mA max.
nx-148e lcd keypad dimensions width	6.4"
nx-148e lcd keypad dimensions height	5.3"
nx-148e lcd keypad dimensions depth	1.0"

Enclosure and Shipping

metal enclosure dimension width	11.25"
metal enclosure dimension height	11.25"
metal enclosure dimension depth	3.50"
shipping weight	9 lbs.
