GE NetworX NX-6 User Manual

Page
36
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
133
28
ZONE TYPE 12 CHARACTERISTIC SELECT 457-125-45678 _____ _____ _____
134
28
ZONE TYPE 13 ALARM EVENT CODE 4 ____
135
28
ZONE TYPE 13 CHARACTERISTIC SELECT 0-12458-5678 _____ _____ _____
136
28
ZONE TYPE 14 ALARM EVENT CODE 7 ____
137
28
ZONE TYPE 14 CHARACTERISTIC SELECT 5-12456-5678 _____ _____ _____
138
28
ZONE TYPE 15 ALARM EVENT CODE 5 ____
139
28
ZONE TYPE 15 CHARACTERISTIC SELECT 457-1256-5678 _____ _____ _____
140
28
ZONE TYPE 16 ALARM EVENT CODE 4 ____
141
28
ZONE TYPE 16 CHARACTERISTIC SELECT 0-12456-5678 _____ _____ _____
142
28
ZONE TYPE 17 ALARM EVENT CODE 7 ____
143
28
ZONE TYPE 17 CHARACTERISTIC SELECT 5-1245-25678 _____ _____ _____
144
28
ZONE TYPE 18 ALARM EVENT CODE 5 ____
145
28
ZONE TYPE 18 CHARACTERISTIC SELECT 457-125-25678 _____ _____ _____
146
28
ZONE TYPE 19 ALARM EVENT CODE 4 ____
147
28
ZONE TYPE 19 CHARACTERISTIC SELECT 0-1245-25678 _____ _____ _____
148
28
ZONE TYPE 20 ALARM EVENT CODE 7 ____
149
28
ZONE TYPE 20 CHARACTERISTIC SELECT 6-1245-25678
_____ _____ _____
ZONE DESCRIPTIONS
1 9
2 10
3 11
4 12
5 13
6 14
7 15
8 16

GE NetworX NX-6 Specifications

Operating Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Loop Specifications

loop resistance for standard loop	300 Ohms Maximum
loop resistance for 2-wire smokes	30 Ohms Maximum
loop response	500mS

Operating Environment

operating temperature	32 to 120 degrees F

LED Keypad Specifications

led keypad current draw	130 mA max.
led keypad dimensions width	6.4"
led keypad dimensions height	4.0"
led keypad dimensions depth	1.1"

NX-148E LCD Keypad Specifications

nx-148e lcd keypad current draw	110 mA max.
nx-148e lcd keypad dimensions width	6.4"
nx-148e lcd keypad dimensions height	5.3"
nx-148e lcd keypad dimensions depth	1.0"

Enclosure and Shipping

metal enclosure dimension width	11.25"
metal enclosure dimension height	11.25"
metal enclosure dimension depth	3.50"
shipping weight	9 lbs.
