Page 25
LOCATION 65
KEYPAD PANIC 2 segments, numerical data
Location 65 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Panic" is enabled in the
partition feature selection Segment 1 contains the tens digit, segment 2 contains the ones digit.
LOCATION 66
KEYPAD MULTIPLE CODE ENTRY (TAMPER) 2 segments, numerical data
Location 66 contains the tens and ones digits that will be sent for a 4+2 format if the keypad "Multiple Code Entry"
(Tamper) is enabled in the partition feature selection. Segment 1 contains the tens digit, segment 2 contains the ones
digit.
LOCATION 67
BOX TAMPER & BOX TAMPER RESTORE 4 segments, numerical data
Location 67 contains the tens and ones digits that will be sent for a 4+2 format if the "Box Tamper" feature is enabled in
location 37. Segment 1 contains the tens digit of the "Box Tamper". Segment 2 contains the ones digit of the "Box
Tamper". Segment 3 contains the tens digit of the "Box Tamper Restore". Segment 4 contains the ones digit of the "Box
Tamper Restore".
LOCATION 68
AC FAIL & AC FAIL RESTORE 4 segments, numerical data
Location 68 contains the tens and ones digits for a 4+2 format that will be sent if "AC Fail Reporting" is enabled.
Segment 1 contains the tens digit of the "AC Fail Reporting". Segment 2 contains the ones digit of the "AC Fail
Reporting". Segment 3 contains the tens digit of the "AC Fail Restore". Segment 4 contains the ones digit of the "AC Fail
Restore".
LOCATION 69
LOW BATTERY & LOW BATTERY RESTORE 4 segments, numerical data
Location 69 contains the tens and ones digits for a 4+2 format that will be sent if "Low Battery Reporting" is enabled..
Segment 1 contains the tens digit of the "Low Battery Reporting". Segment 2 contains the ones digit of the "Low Battery
Reporting". Segment 3 contains the tens digit of the "Low Battery Restore". Segment 4 contains the ones digit of the
"Low Battery Restore".
LOCATION 70
AUX POWER OVER-CURRENT & RESTORE 4 segments, numerical data
Location 70 contains the tens and ones digits for a 4+2 format that will be sent if "Aux Power Over-current Reporting" is
enabled. Segment 1 contains the tens digit of the "Aux Power Over-current Reporting". Segment 2 contains the ones
digit of the "Aux Power Over-current Reporting". Segment 3 contains the tens digit of the "Aux Power Over-current
Restore". Segment 4 contains the ones digit of the "Aux Power Over-current Restore".
LOCATION 71
BELL TAMPER & RESTORE 4 segments, numerical data
Location 71 contains the tens and ones digits for a 4+2 format that will be sent if siren supervision reporting is enabled.
Segment 1 contains the tens digit of the "Bell Tamper Reporting". Segment 2 contains the ones digit of the "Bell Tamper
Reporting". Segment 3 contains the tens digit of the "Bell Tamper Restore". Segment 4 contains the ones digit of the
"Bell Tamper Restore".
LOCATION 72
TELEPHONE LINE CUT & RESTORE 4 segments, numerical data
Location 72 contains the tens and ones digits for a 4+2 format that will be sent if "Telephone Line Cut Reporting" is
enabled. Segment 1 contains the tens digit of the "Telephone Line Cut Reporting". Segment 2 contains the ones digit of
the "Telephone Line Cut Reporting". Segment 3 contains the tens digit of the "Telephone Line Cut Restore". Segment 4
contains the ones digit of the "Telephone Line Cut Restore".
LOCATION 74
EXPANDER TROUBLE & RESTORE 4 segments, numerical data
Location 74 contains the tens and ones digits for a 4+2 format that will be sent if "Expander Trouble Reporting" is
enabled. Segment 1 contains the tens digit of the "Expander Trouble Reporting". Segment 2 contains the ones digit of
the "Expander Trouble Reporting". Segment 3 contains the tens digit of the "Expander Trouble Restore". Segment 4
contains the ones digit of the "Expander Trouble Restore".
LOCATION 75
FAIL TO COMMUNICATE 2 segments, numerical data
Location 75 contains the tens and ones digits for a 4+2 format that will be sent if the "Fail To Communicate Reporting" is
enabled. Segment 1 contains the tens digit, segment 2 contains the ones digit.
