CUSTOMIZING ZONE TYPES (Configuration Groups)
LOCATIONS 110-149 ARE USED TO CHANGE THE ZONE TYPES AS LISTED IN THE TABLE ON PAGE 18.
THESE LOCATIONS ARE CONSIDERED ADVANCED PROGRAMMING AND SHOULD ONLY BE CHANGED WITH
A THOROUGH UNDERSTANDING OF THE OPERATION OF EACH BIT.
LOCATION 110
ZONE TYPE 1 ALARM EVENT CODE
1 segment, numerical data
Location 110 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from
the list on page 38. The zone ID will be that zone that is in alarm. If 4+2 format is being used, the number programmed
in this location will be sent as the tens digit. When using 4+2 the digit in location 110 should be from 1-15. The zone ID
for 4+2 formats will be the ones digit of the zone that is in alarm.
LOCATION 111
ZONE TYPE 1 CHARACTERISTICS
3 segments, feature selection
Table 3.1
Segment 1
â Fire (turn on if this is a fire zone).
ã 24 hour (turn on for non-fire 24 hour zones).
ä Keyswitch zone. (normally open switch)
å Follower (turn on for burglary zones that are Instant during non-entry times).
æ Delay 1 zone (follows timer 1 entry and exit times).
ç Delay 2 zone (follows timer 2 entry and exit times).
è Interior (turn on if this zone should Automatically Bypass or Bypass for Stay Arming).
é Local only (turn on if this zone should not be reported).
Segment 2
â On will beep the keypad for alarm.
ã On will sound the yelping siren for alarm.
ä On if zone type will sound the temporal siren for alarm.
å On if zone type will chime.
æ On if zone type can be bypassed.
ç On if zone type is included in the group shunt.
è On if zone type is force armable.
é On if zone type is entry guard.
Segment 3
â RESERVED
ã On enables Double End Of Line (D.E.O.L.) Tamper zone. Mainly used for tamper on wireless
zones.
ä On enables Trouble Reporting zone. (Day zone and Fire zones)
å On if zone type is a Cross Zone.
æ On enables Dialer Delay zone. (See location 40, page 20)
ç On if zone type will swinger shutdown. (See location 38, page 20)
è On enables Restore reporting.
é On enables Listen-In. (See location 40, page 20)
LOCATION 112 -
LOCATION 149
ZONE TYPES 2 THROUGH 20
Locations 112 - 149 contain the remaining 19 Zone Types information. Locations 112 and 113 correspond to Zone Type
2, and Locations 148 and 149 correspond to Zone Type 20. The EVEN numbered locations reflect the Zone Type Alarm
Event Code while the ODD numbered locations designate the Zone Type Characteristics. Use the description found in
Location 110 for programming the Alarm Event Codes, and use Table 3.1 shown above to select the Zone Type
Characteristics. Refer also to the Programming Worksheets.
