GE NetworX NX-8-EUR User Manual

42 53 GO TO PROGRAM CODE
9-7-1-3-0-0
GO TO PROGRAM CODE PARTITION AND AUTHORIZATION
Segment 1 (Circle Numbers To Program)
1 Reserved
2 Enables “Go To Program Code” as an arm only code
3 Enables “Go To Program Code” as an arm only code after closing
4 Enables “Go To Program Code” as a master arm/disarm code (can change user codes)
5 Enables “Go To Program Code” as an arm/disarm code
6 Enables “Go To Program Code” to bypass zones
7 Enables “Go To Program Code” opening and closing reports
8 Reserved
Segment 2 (Circle Numbers To Program)
1 Enables “Go To Program Code” for partition #1.
2 Enables “Go To Program Code” for partition #2.
3 Enables “Go To Program Code” for partition #3.
4 Enables “Go To Program Code” for partition #4.
5 Enables “Go To Program Code” for partition #5.
6 Enables “Go To Program Code” for partition #6.
7 Enables “Go To Program Code” for partition #7.
43
54
8 Enables “Go To Program Code” for partition #8.
44 54 DURESS CODE
15-15-15-15-15-15
AUXILIARY OUTPUTS 1-4 PARTITION SELECTION
Segments 1 2 3 4
Partition 1 1 1 1 1
Partition 2 2 2 2 2
Partition 3 3 3 3 3
Partition 4 4 4 4 4
Partition 5 5 5 5 5
Partition 6 6 6 6 6
Partition 7 7 7 7 7
45 55
Partition 8 8 8 8 8
AUXILIARY OUTPUTS 1-4 SPECIAL TIMING
Segments 1 2 3 4
Auxiliary output timed in minutes 1 1 1 1
Auxiliary output to latch 2
2
2 2
Auxiliary output to stop timing when user code is entered
3
3
3 3
Auxiliary output to activate only between closing and opening time 4 4 4 4
Auxiliary output to activate only between opening and closing time 5 5 5 5
Invert auxiliary output (0 volts going to 12 volts when activated) 6 6
6
6
Reserved 7 7 7 7
46 55
Reserved 8 8 8 8
AUXILIARY OUTPUT 1, EVENT & TIME (relays 1 and open collector 1)
Segment 1
Program the event number for output 1
7=Each siren activation
47 55
Segment 2
Program the timing for output 1
0 sec.=follow event
AUXILIARY OUTPUT 2, EVENT & TIME (relays 2 and open collector 2)
Segment 1
Program the event number for output 2
7=Each siren activation
48 56
Segment 2
Program the timing for output 1
0 sec.=follow event
AUXILIARY OUTPUT 3, EVENT & TIME (open collector 3)
Segment 1
Program the event number for output 3
2=24 hour alarm
49 56
Segment 2
Program the timing for output 3
10=10 sec.
AUXILIARY OUTPUT 4, EVENT & TIME (open collector 4)
Segment 1
Program the event number for output 4
21=armed
50 56
Segment 2
Program the timing for output 4
0=follow event
NX-8-EUR Installation manual Page 92 02/07/06
