Page 24 NX1448E Icon Keypad
3 ZONE LOW BATTERY - Press the [3] key. The zone icon(s) will
illuminate showing which zone(s) has a low battery. This only
applies to wireless zones. Press the [#] key to return to the 1 of 8
service icons.
4 ZONE LOSS OF SUPERVISION - Press the [4] key and the zone
icon(s) will illuminate showing which zone(s) has loss of
supervision. This only applies to wireless zones. Press [#] key to
return to the 1 of 8 service icons.
5 RESERVED
TELEPHONE LINE TROUBLE/LINE CUT – Press the [6] key. The
zone icon(s) will illuminate as they correspond to these service
conditions:
1-5 = Reserved 6 = Telephone Line Trouble / Line Cut
7 = Aux communication device failure
6
The service icon will remain lit until the trouble clears and a user
code is entered. * SEE NOTE AT END OF TABLE.
7 FAILURE TO COMMUNICATE - This icon will illuminate when
there is a failure to communicate between your system and the
central station. * SEE NOTE AT END OF TABLE.
8 LOSS OF SYSTEM TIME - This icon will illuminate when there
has been a loss of power and your system clock needs to be reset.
Refer to page 22. * SEE NOTE AT END OF TABLE.
# EXIT - Press the [#] key to exit the Service Menu.
* NOTE to Icons 6,7,8: This fault is global in nature and will affect
all partitions of a multi-partition system.
