GE OEC 9800 C-Arm - Image Intensifier and Camera Section; II, Camera Parts List

10
OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-311114-12 Screw, NA, Socket, Hex, 1/4-20, 3/4, SZC, 8 2x
2 00-880691-01 Machining, Cover, Camera 1
3 00-881130-01 Weight, Counter, Rear, 9-Inch 1
4 12-225108-08 Screw, SEMS, Spring, Pan, Torx, 8x32, 1 2
5 00-880854-01 Shield, Camera, EMI, 9-Inch 1
6 12-225106-06 Screw, SEMS, Spring, Pan, Torx, 6x32, 3/8, SCZ 8
7 51-500507-00 Hardware Kit, Connector, Jack, Socket, Set, 4-40, .50L 2
8 00-880688-01 Weldment, Mount, Connector, Camera, Cover 1
9 00-877690-01 Shield, Cover, Camera 1
10 12-312060-08 Screw, NA, Socket, Hex, 10-32, 1/2, SST 3
11 12-225106-20 Screw, SEMS, Spring, Pan, Torx, 6-32, 1, SCZ 4
12 00-879126-01 Assembly, CCD Camera, 1K x 1K, 9" 1
12 00-879127-01 Assembly, CCD Camera, 1K x 1K, 12" 1
13 22-429863-00 Standoff, Hex, M/F, 1/4-20, 3.250L, SST 12
14 00-901226-02 Intensifier, Image, HX, Rear Mount, 9" 1
14 00-901083-01 Intensifier, Image, HX, Rear Mount, 12" 1
15 00-871303-01 Gasket, X-Ray Grid 1
16 00-901200-01 Grid, X-Ray, 10.1, 9-Inch 1
17 12-215004-05 Screw, Machine, Flange, Torx, 4-40, 5/16, SZC 6
18 12-225108-12 Screw, SEMS, Spring, Pan, Torx, 8x32, 3/4, SCZ 4
19 00-881075-01 Handle C 2
20 12-225108-12 Screw, SEMS, Spring, Pan, Torx, 8x32, 3/4, SCZ 4
21 12-311114-12 Screw, NA, Socket, Hex, 1/4-20, 3/4, SZC, 8 4
22 00-881193-01 Assembly, Mount, Image Intensifier, 9-Inch 1
23 12-313915-20 Screw, NA, Socket, Hex, 5/16-18, 1, SBO, 8 4
Figure 2. II, Camera Parts List
