OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 12-225108-08 Screw, SEMS, Spring, Pan, Torx, 8x32, 1 4
2 00-879829-01 Cover, Front, Top 1
3 12-225108-08 Screw, SEMS, Spring, Pan, Torx, 8x32, 1 4
4 00-881292-01 Cover, Leg, Front 1
5 12-311114-12 Screw, NA, Socket, Hex, 1/4-20, 3/4, SZC, 8 2
6 12-225160-06 Screw, SEMS, Spring, Pan, Torx, 10x32 4
7 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8x32, 3/8, SZC 3
8 00-880428-01 Cover, Front, Right 1
9 12-313915-26 Screw, NA, Socket, Hex, 5/16-18, 1 3/4, SBO, 8 4
10 00-880897-01 End Cap, Cross Beam 2
11 12-225160-06 Screw, SEMS, Spring, Pan, Torx, 10x32 2
12 00-876038-01 Cover, Cross Beam 1
13 13-311106-00 Nut, Hex-Lock-External-T, 6-32, SST, NA, A=.313 2
14 00-879830-01 Assembly, Rear Cover 1
15 00-876692-02 Cover, Label, Back Door 1
16 12-311115-20 Screw, NA, Socket, Hex, 5/16-18, 1, SZC, 8 3
17 00-877505-01 Spacer, Cover, Label 1
18 00-877478-01 Panel, Label 1
19 00-877388-02 Stiffner, Cover Label 1
20 00-880427-01 Cover, Front, Left 1
21 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 10x32 3
22 00-901627-02 Assembly, Hand Control, 4 Button 1
23 00-881060-02 Assembly, Footswitch 1
Figure 1. Covers Parts List
