OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 00-879982-01 Cover, Generator Driver 1
2 20-840090-00 Fan, Axial, Blo, 12VDC, 25CFM, 3050RPM 1
3 12-255106-22 Screw, SEMS, Spring, Pan, Torx, 6-32, 1-1/4, SZC 3
4 00-881125-01 Duct, Fan 1
5 12-225108-08 Screw, SEMS, Spring, Pan, Torx, 8-32, 1/2, SZC 2
6 12-225106-08 Screw, SEMS, Spring, Pan, Torx, 6-32, 1/2, SZC 4
7 00-879694-01 Cover, Front, Card Rack 1
8 12-225108-08 Screw, SEMS, Spring, Pan, Torx, 8-32, 1/2, SZC 8
9 00-879992-01 Cover, Component tray 1
10 14-181110-00 Washer, Plain, #10, SST, MS15795-808, ID=.221 1
11 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8-32, 3/8, SZC 1
12 12-225108-06 Screw, SEMS, Spring, Pan, Torx, 8-32, 3/8, SZC 9
13 00-881127-01 Ring, Expansion Chamber 1
14 12-225104-04 Screw, SEMS, Spring, Pan, Torx, 4-40, 1/4, SZC 4
Figure 4. Internal Cover Parts List
