OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 23-601001-00 Clip, Panel, .250D, .850, Nylon, White 1
2 00-879978-01 Guard, Safety 1
3 12-225108-08 Screws, SEMS, Spring, Pan, Torx, 8-32, 1/2, SZC 2
4 12-225160-06 Screws, SEMS, Spring, Pan, Torx, 10-32, 3/8, SZC 2
5 14-121110-00 Washer, Plain, #10, SST, MS15795-808, ID=.211 2
6 14-121110-00 Washer, Plain, #10, SST, MS15795-808, ID=.211 2
7 00-881324-01 Bracket, EMI 1
8 00-900987-01 Tank, High Voltage 1
9 14-121114-00 Washer, Plain, 1/4, SST, MS15795-810, ID=.276 1
10 14-211114-00 Washer, Lock-HLCL, Spring, 1/4, SST, MS35338 1
11 13-111114-00 Nut, Hex, 1/4-20, SST, MS51971-1 1
12 00-901404-01 Insulator, IGBT 2
13 00-880405-01 Assembly, IGBT/Snubber 1
14 14-121110-00 Washer, Plain, #10, SST, MS15795-808, ID=.211 4
15 14-152003-00 Washer, Lock-HLCL,#10, SST, MS35365-60 4
16 12-312060-30 Screw, NA, Socket, Hex, 10-32, 2, SST 4
Figure 10. IGBT/Snubber, Tank Parts List
