OEC 9800 C-Arm Illustrated Parts Manual
Contents Installation Service Schematics Periodic Maintenance Illustrated Parts
Item Part Number Description Qty
1 20-842001-00 Coupling, Shaft, 5/8ID, 1.312OD, SBO 1
2 00-879030-01 Shaft, Tiller, Lower, Steering 1
3 00-901101-01 Key, U-Joint, Rear Steering 1
4 00-879939-01 Universal Joint, Lower, Steering 1
5 12-225160-20 Screw, SEMS, Spring, Pan, Torx, 10-32, 1, SZC 4
6 21-109586-00 Bearing, Ball, 1.181ID, 1.8504OD, .3543WD 1
7 00-879027-01 Shaft, Tiller, Short, Steering 1
8 21-109947-00 Bearing, call, .625ID, 1.375OD, .4375WD 1
9 00-878942-01 Sprocket, Drive, Steering 1
10 19-224945-00 Pin Spring, .250OD, 1, SZC 1
11 14-900012-00 Washer, Plain, #10, SZC, NA, ID=.219, OD=.500 6
12 14-211110-00 Washer, Lock, Helical-Spring, #10, SZC, NA, ID-.194 3
13 12-311110-12 Screw, NA, Socket, Hex, 10-24, 3/4, SZC, 8 3
14 00-878945-01 Cam, Detent, Steering 1
15 22-678621-00 Ring, Retaining, External, Basic, 5/8, Spring, Steel 1
16 00-901102-01 Key, Rear, Steering 1
17 00-879026-01 Housing, Bearing, Tiller, Steering 1
18 00-901101-01 Key, U-Joint, Rear Steering 1
Figure 24. Rear Steering Parts List (1 of 2)
